ACO Therm® Block mit Fensteraussparung

Produktvorteile

Wärmebrückenfreie Lichtschachtmontage
Umlaufender Abdichtungsflansch
Frei positionierbarer Lichtschacht
Fertige Oberfläche
Verputzen und Streichen im Lichtschacht entfällt
Wärmeleitwert Dämmstoff 0,025 W/(mK)
Kosten- und zeitsparende Montage
Platte kann um 180° gedreht werden

Produktinformationen

Montierbare Lichtschächte
- 1000 x 600 x 400 mm
- 1000 x 1000 x 400 mm
- 1000 x 1300 x 400 mm
- 1000 x 1000 x 600 mm
- 1000 x 1300 x 600 mm
- 1250 x 1000 x 400 mm
- 1250 x 1300 x 600 mm

Infobox

BIM

Die aktuellste BIM Revit Version finden Sie in der Tabelle "Bestellinformationen" in der Spalte "Downloads".

Ältere Revit Versionen finden Sie unter: BIM.

Abmessungen		Für Leibungsfenster	Fensteraussparung im Therm Block	Artikel-Nr.
Breite	Höhe	Breite x Höhe	Breite x Höhe
[mm]	[mm]	[mm]	[mm]

1500	1400		460 x 460	315976
		750 x 500	710 x 460	315977
		800 x 600	760 x 560	315727
		1000 x 500	960 x 460	315729
		1000 x 625	960 x 585	315730
		1000 x 750	960 x 710	315731
		1000 x 1000	960 x 960	315750

1230	1400		460 x 460	375211
		750 x 500	710 x 460	375212
		800 x 600	760 x 560	375213
		1000 x 500	960 x 460	375215
		1000 x 625	960 x 585	375216
		1000 x 750	960 x 710	375217
		1000 x 1000	960 x 960	375219
1500	1400	500 x 500	460 x 460	315979
		750 x 500	710 x 460	315980
		800 x 600	760 x 560	315738
		1000 x 500	960 x 460	315740
		1000 x 625	960 x 585	315741
		1000 x 750	960 x 710	315742
		1000 x 1000	960 x 960	315749
	1700	500 x 500	460 x 460	315990
		750 x 500	710 x 460	315991
		800 x 600	760 x 560	315743
		1000 x 500	960 x 460	315745
		1000 x 625	960 x 585	315746
		1000 x 750	960 x 710	315747
		1000 x 1000	960 x 960	315748

1230	1400		460 x 460	375222
		750 x 500	710 x 460	375223
		800 x 600	760 x 560	375224
		1000 x 500	960 x 460	375227
		1000 x 625	960 x 585	375228
		1000 x 750	960 x 710	375229
		1000 x 1000	960 x 960	375232
1500	1400		460 x 460	315982
		750 x 500	710 x 460	315983
		800 x 600	760 x 560	315640
		1000 x 500	960 x 460	315641
		1000 x 625	960 x 585	315642
		1000 x 750	960 x 710	315643
		1000 x 1000	960 x 960	315644
	1700		460 x 460	315993
		750 x 500	710 x 460	315994
		800 x 600	760 x 560	315645
		1000 x 500	960 x 460	315646
		1000 x 625	960 x 585	315647
		1000 x 750	960 x 710	315648
		1000 x 1000	960 x 960	315649

1230	1400		460 x 460	375234
		750 x 500	710 x 460	375235
		800 x 600	760 x 560	375236
		1000 x 500	960 x 460	375238
		1000 x 625	960 x 585	375239
		1000 x 750	960 x 710	375240
		1000 x 1000	960 x 960	375242
1500	1400		460 x 460	380173
		750 x 500	710 x 460	380174
		800 x 600	760 x 560	380175
		1000 x 500	760 x 460	380176
		1000 x 625	960 x 585	380177
		1000 x 750	960 x 710	380178
		1000 x 1000	960 x 960	380180
	1700		460 x 460	380209
		750 x 500	710 x 460	380210
		800 x 600	760 x 560	380211
		1000 x 500	960 x 460	380212
		1000 x 625	960 x 585	380213
		1000 x 750	960 x 710	380214
		1000 x 1000	960 x 960	380216

1230	1400		460 x 460	375244
		750 x 500	710 x 460	375245
		800 x 600	760 x 560	375246
		1000 x 500	960 x 460	375248
		1000 x 625	960 x 585	375249
		1000 x 750	960 x 710	375250
		1000 x 1000	960 x 960	375252
1500	1400		460 x 460	380182
		750 x 500	710 x 460	380183
		800 x 600	760 x 560	380184
		1000 x 500	960 x 460	380185
		1000 x 625	960 x 585	380186
		1000 x 750	960 x 710	380187
		1000 x 1000	960 x 960	380189
	1700		460 x 460	380218
		750 x 500	710 x 460	380219
		800 x 600	760 x 560	380220
		1000 x 500	960 x 460	380221
		1000 x 625	960 x 585	380222
		1000 x 750	960 x 710	380223
		1000 x 1000	960 x 960	380225

1230	1400		460 x 460	375254
		750 x 500	710 x 460	375255
		800 x 600	760 x 560	375256
		1000 x 500	960 x 460	375258
		1000 x 625	960 x 585	375259
		1000 x 750	960 x 710	375260
		1000 x 1000	960 x 960	375262
1500	1400		460 x 460	380191
		750 x 500	710 x 460	380192
		800 x 600	760 x 560	380193
		1000 x 500	960 x 460	380194
		1000 x 625	960 x 585	380195
		1000 x 750	960 x 710	380196
		1000 x 1000	960 x 960	380198
	1700		460 x 460	380227
		750 x 500	710 x 460	380228
		800 x 600	760 x 560	380229
		1000 x 500	960 x 460	380230
		1000 x 625	960 x 585	380231
		1000 x 750	960 x 710	380232
		1000 x 1000	960 x 960	380234

1230	1400		460 x 460	375264
		750 x 500	710 x 460	375265
		800 x 600	760 x 560	375266
		1000 x 500	960 x 460	375268
		1000 x 625	960 x 585	375269
		1000 x 750	960 x 710	375270
		1000 x 1000	960 x 960	375272
1500	1400		460 x 460	380200
		750 x 500	710 x 460	380201
		800 x 600	760 x 560	380202
		1000 x 500	960 x 460	380203
		1000 x 625	960 x 585	380204
		1000 x 750	960 x 710	380205
		1000 x 1000	960 x 960	380207
	1700		460 x 460	380236
		750 x 500	710 x 460	380237
		800 x 600	760 x 560	380238
		1000 x 500	960 x 460	380239
		1000 x 625	960 x 585	380240
		1000 x 750	960 x 710	380241
		1000 x 1000	960 x 960	380243
